# how to find elbow degree offset pipe | how to find travel pipe length

how to find travel pipe length

how to find elbow degree offset pipe

how to calculation piping elbow center any degree

how to fabrication rolling pipe

any degree elbow center formula

how to calculation offset pipe degree

how to find offset pipe elbow degree

pipe size 8 inch

flange dimension 110 mm

equal Tee 8″   dimension 176 mm

running pipe dimension 1884 — 110 mm = 1774

how to calculate offset pipe degree

how to find offset pipe elbow degree

tan‾1( 2800 ÷ 1774 = 57.6 degree

57.6 degree elbow center formula

57.6 ÷ 2 = 28.8

tan( 28.8 ) × 1.5 × 25.4 = 20.9

8 inch × 20.9 = 167 mm elbow center

1774 – 167 = 1607 mm

how to calculation offset pipe travel length

8 inch × 20.9 = 167 mm elbow center

1774 – 167 = 1607 mm

tan‾1( 2800 ÷ 1607 = 60 degree

elbow  60 degree is

60 degree elbow center formula any size

60 ÷ 2 = 30 degree

tan( 30 ) × 1.5 × 25.4 = 22

8 inch × 22 = 176 mm elbow center 60 degree

√( 2800 ^2 + 1607^2 = 3228.3

3228.3 – 176 elbow center = 3052.3

3052.3 – 176 Tee dimensions = 2876 travel pipe length
